中小型企業與使用最新企業移動設備為員工提供競爭優勢的行業巨頭競爭，但您預算中的智能手機無法提供您所需的功能。介紹均衡器 — Zebra TC22 / TC27 移動數據終端。TC22/TC27 是非常成功的 TC2x 系列的第三代產品，它提供了世界上最好的智能手機造型和定價，以及可提高生產力和客戶服務質量的大型業務功能。這款緊湊、功能強大的設備提供 6 英吋大顯示屏、5G、Wi-Fi 6E、集成掃描儀、支持點擊支付和其他非接觸式交易等。這款耐用的設備比消費類手機更耐用，可提供更好的投資回報。Zebra 的服務組合可以幫助您讓您的設備保持最佳性能。借助 TC22/TC27 獲得與任何規模的企業競爭所需的動力 — 員工想要的智能手機風格、您的企業所需的功能，而且價格您可以承受。
TC22 – Wifi 6E
TC27 – Wifi 6E / 5G
描述
中小型企業與使用最新企業移動設備為員工提供競爭優勢的行業巨頭競爭，但您預算中的智能手機無法提供您所需的功能。介紹均衡器 — Zebra TC22/TC27 移動數據終端。TC22/TC27 是非常成功的 TC2x 系列的第三代產品，它提供了世界上最好的智能手機造型和定價，以及可提高生產力和客戶服務質量的大型業務功能。這款緊湊、功能強大的設備提供 6 英寸大顯示屏、5G、Wi-Fi 6E、集成掃描儀、支持點擊支付和其他非接觸式交易等。這款耐用的設備比消費類手機更耐用，可提供更好的投資回報。Zebra 的服務組合可以幫助您讓您的設備保持最佳性能。借助 TC22/TC27 獲得與任何規模的企業競爭所需的動力 — 員工想要的智能手機風格、您的企業所需的功能，而且價格您可以承受。
同時為您的所有應用程序提供支持
下一代處理器可提供上一代性能兩倍的性能，並提供一流的內存和數據存儲選項，讓您的所有應用程序獲得卓越的性能。
最好的無線技術
在無線方面，TC22/TC27 提供了一切。5G 和 Wi-Fi 6/6E 提供有線速度，為工作人員在設施內外提供更好的語音和數據性能。
Android 的精華——今天和明天
通過 Android 16 提供的支持可確保您不會因操作系統的發展而無法滿足需求 — 您的設備每天都可以使用最新功能。
使用先進的 6 英寸 FHD+ 顯示屏查看更多內容並減少滾動次數
更大的屏幕提供了更多的顯示空間，明亮的 450 尼特屏幕無論在室內還是室外，都可以輕鬆閱讀。
以更短的時間、更少的精力採集條形碼
與使用手機攝像頭掃描相比，Zebra 的企業級掃描選項使工作人員能夠以近一半的時間和一半的體力來採集條碼。4選擇 SE4710 1D/2D 標準掃描引擎或採用 Intellifocus TM技術的 SE55 1D/2D 高級範圍掃描引擎，能夠掃描手中或最高倉庫貨架上的物品。無論條件如何，這兩種選項都可以瞬間捕獲幾乎每個條形碼。
為非接觸式交易世界做好準備
輕鬆將 TC22/TC27 與您現有的 POS 非接觸式支付解決方案集成，讓客戶只需輕輕一按即可付款。此外，對 Apple VAS 和 Google SmartTap 的內置支持使 TC22/TC27 能夠讀取 Apple 或 Google 錢包中存儲的機票、會員卡和禮品卡、登機牌等。
Zebra TC27 / TC22 規格
| 尺寸 | 6.5 英吋 (長) x 3.0 英吋 ( 寬 ) x 0.49 英吋 ( 深 ) 165 毫米長 x 76.3 毫米寬 x 12.5 毫米深 |
| 重量 | 8.32 安士 / 236 克（TC22 3800mAh 電池） |
| 顯示屏 | 6.0 英吋彩色全高清+ (1080 x 2160)；LED背光源；450 尼特；康寧®大猩猩®玻璃 |
| 電池 | 用戶可拆卸、可充電鋰離子電池、PowerPrecision 用於實時電池指標； 標準容量：3800mAh/14.63Wh； 擴展容量：5200mAh/20.02Wh； BLE電池：3800mAh/14.63Wh |
| 外加插槽 | User accessible MicroSD card supports up to 2 TB |
| CPU | Qualcomm® 5430 六核，2.1 GHz |
| 操作系統 | Upgradeable to Android 16 |
| 記憶體 | 6 GB RAM/64 GB Flash; 8 GB RAM/128 GB Flash |
| 操作温度 | 14°F 至 122°F/-10°C 至 50°C |
| 跌落規格 | 超過工作溫度（-10°C 至 50°C/14°F 至 122°F），多次從 5 ft./1.5 m 處跌落到混凝土上，並按照 MIL-STD-810H 進行多次 4.5 ft/1.3 m 跌落至瓷磚 上混凝土超過工作溫度（-10°C 至 50°C/14°F 至 122°F），符合 MIL-STD 810H |
| IP 密封 | IP68 和 IP65，帶電池符合適用的 IEC 密封規範 |
| 掃瞄器 | SE55 1D/2D Advanced Range Scan Engine with IntelliFocus™ technology; SE4770 1D/2D Scan Engine |
| TC27 Only: Radio Frequency Band | North America: 5G FR1: n2/5/7/12/13/14/25/26/29/38/41/48/66/71/77/78; 4G: B2/4/5/7/12/13/14/17/25/26/29/38/41/48/66/71; 3G: B2/4/5; Rest of World: 5G FR1: n1/2/3/5/7/8/20/28/38/40/41/66/71/77/78; 4G: B1/2/3/4/5/7/8/13/17/20/28/38/39/40/41/42/43/66/71; 3G: 1/2/4/5/8; 2G: 850/900/1800/1900; China/Japan: 5G FR1: n1/3/5/7/8/28/38/40/41/77/78/79; 4G: B1/3/5/7/8/19/18/26/28/34/38/39/40/41/42; 3G: B1/5/6/8/19; 2G: 850/900/1800; Dual SIM/Dual Standby, VoLTE, Gigabit LTE-A, 5G NR Sub-6 (NSA, SA), LTE/NR Carrier Aggregation, supports private networking (LTE/5G) |
| Wifi | IEEE 802.11 a/b/g/n/ac/d/h/i/r/k/v/w/mc/ax; 2×2 MU-MIMO, Wi-Fi 6E (802.11ax), Wi-Fi™ certified; Wi-Fi™ 6 Certified, Dual Band Simultaneous; IPv4, IPv6 |
| 藍牙 | Class 2, Bluetooth v5.2 and Secondary BLE for beaconing within BLE battery |
| NFC | ISO 14443 Type A and B; FeliCa and ISO 15693 cards; Card Emulation via Host; Contactless payment support; ECP1.0 and ECP2.0 polling support; Apple VAS certified |
| 相機 | 主相機 16 MP 前置相機 5 MP |
Part Number
| Part Number | Description |
|---|---|
| WLMT0-T22B6ABC2-A6 | TC22; WLAN, Wifi 6, SE4710, 6 Display, 6GB/64GB, 16MP RFC, 5MP FFC, 2-Pin Back I/O, Standard Battery, NFC, BT, USB-C, GMS, ROW |
| WLMT0-T22B8ABC8-A6 | TC22; WLAN, WIFI 6, SE4710, 6 DISPLAY, 8GB/128GB, 16MP RFC, 5MP FFC, 8-PIN BACK I/O, STANDARD BATTERY, NFC, BT, USB-C, GMS, ROW |
| WLMT0-T22B6CBC2-A6 | TC22; WLAN, Wifi 6, SE55, 6 Display, 6GB/64GB, 16MP RFC, 5MP FFC, 2-Pin Back I/O, Standard Battery, NFC, BT, USB-C, GMS, ROW |
| WLMT0-T22B8ABD8-A6 | TC22; WLAN, Wifi 6, SE4710, 6 Display, 8GB/128GB, 16MP RFC, 5MP FFC, 8-Pin Back I/O, Standard Battery w/BLE, NFC, BT, USB-C, GMS, ROW |
| WLMT0-T22B8CBD8-A6 | TC22; WLAN, Wifi 6, SE55, 6 Display, 8GB/128GB, 16MP RFC, 5MP FFC, 8-Pin Back I/O, Standard w/BLE Battery, NFC, BT, USB-C, GMS, ROW |
| WLMT0-T22B6ABE2-A6 | TC22; WLAN, Wifi 6, SE4710, 6 Display, 6GB/64GB, 16MP RFC, 5MP FFC, 2-Pin Back I/O, Extended Battery, NFC, BT, USB-C, GMS, ROW |
Accessories
| Part Number | Description |
|---|---|
| PWR-BGA12V50W0WW | Level VI AC/DC Power Supply Brick. AC Input: 100-240V, 2.4A. DC Output: 12V, 4.16A, 50W. Requires: DC Line Cord and Country Specific AC Grounded Line Cord |
| CBL-DC-388A1-01 | DC Line Cord for Running the Single Slot Cradles or Battery Chargers from a Single Level VI Power Supply PWR-BGA12V50W0WW, Level VI Replacement for PWRS-14000-148R |
| CBL-TC5X-USBC2A-01 | USB C TO USB A COMMUNICATIONS AND CHARGING CABLE, 1M LONG, CAN BE USED WITIH VEHICLE CRADLE # CRD-TC56-CVCD2-02. |
| PWR-WUA5V12W0US | USB Power Supply, 100-240 VAC Input with US plug, Output = 5 V, 2.5 A |
| PWR-BGA12V108W0WW | Level VI AC/DC Power Supply Brick. AC Input: 100-240V, 2.8A. DC Output: 12V, 9A, 108W. Requires: DC line cord and Country specific grounded AC line cord. |
| 25-124330-01R | Micro USB Active-Sync Cable. Allows for Active-Sync Connectivity Between the Mobile Computer Single or Two Slot Cradle and a Host Device. Also Used to Connect the MS4717 Fixed Mount Imager to a USB Host for Communication |
| CBL-DC-381A1-01 | DC Line Cord for running multi-slot cradles from a single Level VI power supply PWR-BGA12V108W0WW (Level VI replacement for PWRS-14000-241R) |
| MOD-MT2-EU1-01 | USB To Ethernet Module. Attaches to the 2-Slot USB/Charging ShareCradle CRD-TC7X-SE2EU1-01 to provide Ethernet support. Mechanical switch selects between USB port and RJ45 Ethernet jack. |
| CRD-TC2L-SE1ET-01 | TC22/TC27 Single Slot Charge & Communication Cradle (shim included). Supports device with boot/trigger handle after shim is removed. Power supply, DC cable, and AC line cord sold separately (PWR-BGA12V50W0WW, CBL-DC-388A1-01) |
| CRD-TC2L-BS5CO-01 | TC22/TC27 5-Slot Charge Only Cradle (shims included). Supports device with boot/trigger handle after shim is removed. Power supply, DC cable, and country specific AC line cord sold separately (PWR-BGA12V108W0WW, CBL-DC-381A1-01) |
| CRD-TC2L-BS1CO-01 | TC22/TC27 Single Slot Charge Only Cradle; Removable shim pre-installed for device without boot, compatible for device with boot/trigger handle without shim. Power supply and USB cable sold separately (PWR-WUA5V12W0US, CBL-TC5X-USBC2A-01) |
| CBL-TC2Y-USBC90A-01 | USB-C cable with 90 degree bend in USB-C adapter |
| SG-TC2L-BOOT-01 | TC22/TC27 Protective Boot |
| SG-TC2L-HSTRP1-01 | TC22/TC27 Handstrap |
| CRD-TC2L-BS11B-01 | TC22/TC27 Single Slot Charge Only Cradle for 1 device & 1 battery (shim included). Supports device with boot/trigger handle after shim is removed. Power supply, DC cable, country specific AC Line Cord sold separately. |
| TRG-TC2L-SNP1-01 | TC22/TC27 Trigger Handle, supports device with either basic or extended battery (requires Protective Boot, sold separately) |
| CRD-TC2L-SE5ET-01 | TC22/TC27 5-Slot Charge & Communication Cradle (shims included). Supports device with boot/trigger handle after shim is removed. Power supply, DC cable, and AC line cord sold separately (PWR-BGA12V108W0WW, CBL-DC-381A1-01) |
| BTRY-TC2L-2XMAXX-01 | TC22/TC27 Standard PowerPrecision LI-ON Battery – 3800 mAh – Single |
| SG-TC2L-HLSTR1-01 | TC22/TC27 Holster, supports device with boot and trigger handle |
| SAC-TC2L-4SCHG-01 | TC22/TC27 4-Slot Battery Charger; Charges up to four Li-ion batteries. Power Supply, DC cable and country specific AC line cord sold separately (PWR-BGA12V50W0WW, CBL-DC-388A1-01) |
| SG-TC2L-SCRNPT1-01 | TC22/TC27 Tempered Glass Screen Protector |
| BTRY-TC2L-2XMAXB-01 | TC22/TC27 Standard PowerPrecision LI-ON Battery with BLE Beacon – 3800 mAh – Single |
| BTRY-TC2L-3XMAXX-01 | TC22/TC27 Extended PowerPrecision LI-ON Battery – 5200 mAh – Single |
| 3PTY-RAM-HOL-ZE24PU | RAM POWERED NON-LOCKING CRADLE FOR ZEBRA TC22/27 WITH BOOT. |
| 3PTY-RAM-HOL-ZE24LU | RAM NON-POWERED LOCKING CRADLE FOR ZEBRA TC22/27 WITH BOOT. |
| 3PTY-RAM-HOL-ZE24-1U | RAM NON-POWERED NON-LOCKING CRADLE FOR ZEBRA TC22/27 WITHOUT BOOT. |
| CRDCUP-TC2L1C-01 | TC22/TC27 Charge Only Cradle Cup, one user swappable cup with shims pre-installed. |
| 3PTY-PCLIP-712348 | ProClip Active Holder for TC22 / TC27 with Rugged Boot, Cig light Adapter. Note: Products sold that do not bear the Zebra brand name are serviced and supported exclusively by their manufacturers in accordance with terms and conditions packaged with the products. Zebra%u2019s Limited Warranty does not apply to products that are not Zebra branded, even if packaged or sold with Zebra products. Please contact the manufacturer directly for technical support and customer service. |
| 3PTY-RAM-HOL-ZE24PL-1U | RAM POWERED LOCKING CRADLE FOR ZEBRA TC22/27 WITHOUT BOOT. |
| 3PTY-RAM-HOL-ZE24L-1U | RAM NON-POWERED LOCKING CRADLE FOR ZEBRA TC22/27 WITHOUT BOOT. |
| 3PTY-RAM-HOL-ZE24PLU | RAM POWERED LOCKING CRADLE FOR ZEBRA TC22/27 WITH BOOT. |
| CRDCUP-TC2L1E-01 | TC22/TC27 Charge and Communications (Ethernet) Cradle Cups. Includes 5 user swappable cups with shims pre-installed. |
| 3PTY-RAM-HOL-ZE24U | RAM NON-POWERED NON-LOCKING CRADLE FOR ZEBRA TC22/27 WITH BOOT. |
| 3PTY-RAM-HOL-ZE24P-1U | RAM POWERED NON-LOCKING CRADLE FOR ZEBRA TC22/27 WITHOUT BOOT. |
| Part Number | Description |
|---|---|
| WCMTB-T27B6ABC2-A6 | TC27; WWAN, 5G, Wifi 6, SE4710, 6 Display, 6GB/64GB, 16MP RFC, 5MP FFC, 2-Pin Back I/O, Standard Battery, NFC, BT, USB-C, SIM & ESIM, GMS, ROW |
| WCMTB-T27B6CBC2-A6 | TC27; WWAN, 5G, Wifi 6, SE55, 6 Display, 6GB/64GB, 16MP RFC, 5MP FFC, 2-Pin Back I/O, Standard Battery, NFC, BT, USB-C, SIM & ESIM, GMS, ROW |
| WCMTB-T27B6ABE2-A6 | TC27; WWAN, 5G, Wifi 6, SE4710, 6 Display, 6GB/64GB, 16MP RFC, 5MP FFC, 2-Pin Back I/O, Extended Battery, NFC, BT, USB-C, SIM & ESIM, GMS, ROW |
| WCMTB-T27B8ABD8-A6 | TC27; WWAN, 5G, Wifi 6, SE4710, 6 Display, 8GB/128GB, 16MP RFC, 5MP FFC, 8-Pin Back I/O, Standard Battery w/BLE, NFC, BT, USB-C, SIM & ESIM, GMS, ROW |
| WCMTB-T27B8CBD8-A6 | TC27; WWAN, 5G, Wifi 6, SE55, 6 Display, 8GB/128GB, 16MP RFC, 5MP FFC, 8-Pin Back I/O, Standard w/BLE Battery, NFC, BT, USB-C, SIM & ESIM, GMS, ROW |
| WCMTB-T27B8ABC8-A6 | TC27; WWAN, 5G, Wifi 6, SE4710, 6 Display, 8GB/128GB, 16MP RFC, 5MP FFC, 8-Pin Back I/O, Standard Battery, NFC, BT, USB-C, SIM & ESIM, GMS, ROW |
| WCMTB-T27B8ABE8-A6 | TC27; WWAN, 5G, Wifi 6, SE4710, 6 Display, 8GB/128GB, 16MP RFC, 5MP FFC, 8-Pin Back I/O, Extended Battery, NFC, BT, USB-C, SIM & ESIM, GMS, ROW |
Accessories
| Part Number | Description |
|---|---|
| PWR-BGA12V50W0WW | Level VI AC/DC Power Supply Brick. AC Input: 100-240V, 2.4A. DC Output: 12V, 4.16A, 50W. Requires: DC Line Cord and Country Specific AC Grounded Line Cord |
| CBL-DC-388A1-01 | DC Line Cord for Running the Single Slot Cradles or Battery Chargers from a Single Level VI Power Supply PWR-BGA12V50W0WW, Level VI Replacement for PWRS-14000-148R |
| CBL-TC5X-USBC2A-01 | USB C TO USB A COMMUNICATIONS AND CHARGING CABLE, 1M LONG, CAN BE USED WITIH VEHICLE CRADLE # CRD-TC56-CVCD2-02. |
| PWR-WUA5V12W0US | USB Power Supply, 100-240 VAC Input with US plug, Output = 5 V, 2.5 A |
| PWR-BGA12V108W0WW | Level VI AC/DC Power Supply Brick. AC Input: 100-240V, 2.8A. DC Output: 12V, 9A, 108W. Requires: DC line cord and Country specific grounded AC line cord. |
| 25-124330-01R | Micro USB Active-Sync Cable. Allows for Active-Sync Connectivity Between the Mobile Computer Single or Two Slot Cradle and a Host Device. Also Used to Connect the MS4717 Fixed Mount Imager to a USB Host for Communication |
| CBL-DC-381A1-01 | DC Line Cord for running multi-slot cradles from a single Level VI power supply PWR-BGA12V108W0WW (Level VI replacement for PWRS-14000-241R) |
| MOD-MT2-EU1-01 | USB To Ethernet Module. Attaches to the 2-Slot USB/Charging ShareCradle CRD-TC7X-SE2EU1-01 to provide Ethernet support. Mechanical switch selects between USB port and RJ45 Ethernet jack. |
| CRD-TC2L-SE1ET-01 | TC22/TC27 Single Slot Charge & Communication Cradle (shim included). Supports device with boot/trigger handle after shim is removed. Power supply, DC cable, and AC line cord sold separately (PWR-BGA12V50W0WW, CBL-DC-388A1-01) |
| CRD-TC2L-BS5CO-01 | TC22/TC27 5-Slot Charge Only Cradle (shims included). Supports device with boot/trigger handle after shim is removed. Power supply, DC cable, and country specific AC line cord sold separately (PWR-BGA12V108W0WW, CBL-DC-381A1-01) |
| CRD-TC2L-BS1CO-01 | TC22/TC27 Single Slot Charge Only Cradle; Removable shim pre-installed for device without boot, compatible for device with boot/trigger handle without shim. Power supply and USB cable sold separately (PWR-WUA5V12W0US, CBL-TC5X-USBC2A-01) |
| CBL-TC2Y-USBC90A-01 | USB-C cable with 90 degree bend in USB-C adapter |
| SG-TC2L-BOOT-01 | TC22/TC27 Protective Boot |
| SG-TC2L-HSTRP1-01 | TC22/TC27 Handstrap |
| CRD-TC2L-BS11B-01 | TC22/TC27 Single Slot Charge Only Cradle for 1 device & 1 battery (shim included). Supports device with boot/trigger handle after shim is removed. Power supply, DC cable, country specific AC Line Cord sold separately. |
| TRG-TC2L-SNP1-01 | TC22/TC27 Trigger Handle, supports device with either basic or extended battery (requires Protective Boot, sold separately) |
| CRD-TC2L-SE5ET-01 | TC22/TC27 5-Slot Charge & Communication Cradle (shims included). Supports device with boot/trigger handle after shim is removed. Power supply, DC cable, and AC line cord sold separately (PWR-BGA12V108W0WW, CBL-DC-381A1-01) |
| BTRY-TC2L-2XMAXX-01 | TC22/TC27 Standard PowerPrecision LI-ON Battery – 3800 mAh – Single |
| SG-TC2L-HLSTR1-01 | TC22/TC27 Holster, supports device with boot and trigger handle |
| SAC-TC2L-4SCHG-01 | TC22/TC27 4-Slot Battery Charger; Charges up to four Li-ion batteries. Power Supply, DC cable and country specific AC line cord sold separately (PWR-BGA12V50W0WW, CBL-DC-388A1-01) |
| SG-TC2L-SCRNPT1-01 | TC22/TC27 Tempered Glass Screen Protector |
| BTRY-TC2L-2XMAXB-01 | TC22/TC27 Standard PowerPrecision LI-ON Battery with BLE Beacon – 3800 mAh – Single |
| BTRY-TC2L-3XMAXX-01 | TC22/TC27 Extended PowerPrecision LI-ON Battery – 5200 mAh – Single |
| 3PTY-RAM-HOL-ZE24PU | RAM POWERED NON-LOCKING CRADLE FOR ZEBRA TC22/27 WITH BOOT. |
| 3PTY-RAM-HOL-ZE24LU | RAM NON-POWERED LOCKING CRADLE FOR ZEBRA TC22/27 WITH BOOT. |
| 3PTY-RAM-HOL-ZE24-1U | RAM NON-POWERED NON-LOCKING CRADLE FOR ZEBRA TC22/27 WITHOUT BOOT. |
| CRDCUP-TC2L1C-01 | TC22/TC27 Charge Only Cradle Cup, one user swappable cup with shims pre-installed. |
| 3PTY-PCLIP-712348 | ProClip Active Holder for TC22 / TC27 with Rugged Boot, Cig light Adapter. Note: Products sold that do not bear the Zebra brand name are serviced and supported exclusively by their manufacturers in accordance with terms and conditions packaged with the products. Zebra%u2019s Limited Warranty does not apply to products that are not Zebra branded, even if packaged or sold with Zebra products. Please contact the manufacturer directly for technical support and customer service. |
| 3PTY-RAM-HOL-ZE24PL-1U | RAM POWERED LOCKING CRADLE FOR ZEBRA TC22/27 WITHOUT BOOT. |
| 3PTY-RAM-HOL-ZE24L-1U | RAM NON-POWERED LOCKING CRADLE FOR ZEBRA TC22/27 WITHOUT BOOT. |
| 3PTY-RAM-HOL-ZE24PLU | RAM POWERED LOCKING CRADLE FOR ZEBRA TC22/27 WITH BOOT. |
| CRDCUP-TC2L1E-01 | TC22/TC27 Charge and Communications (Ethernet) Cradle Cups. Includes 5 user swappable cups with shims pre-installed. |
| 3PTY-RAM-HOL-ZE24U | RAM NON-POWERED NON-LOCKING CRADLE FOR ZEBRA TC22/27 WITH BOOT. |
| 3PTY-RAM-HOL-ZE24P-1U | RAM POWERED NON-LOCKING CRADLE FOR ZEBRA TC22/27 WITHOUT BOOT. |
