| 解析度 |
8 dots/mm (203 DPI) |
12 dots/mm (300 DPI) |
8 dots/mm (203 DPI) |
12 dots/mm (300 DPI) |
| 列印方式 |
Thermal Transfer & Direct Thermal |
| 最高列印速度 |
152.4 mm (6 in)/second |
127 mm (5 in)/second |
152.4 mm (6 in)/second |
127 mm (5 in)/second |
| 最大列印寬度 |
108 mm (4.25 in) |
105.7 mm (4.16 in) |
108 mm (4.25 in) |
105.7 mm (4.16 in) |
| 最大列印長度 |
2,794 mm (110 in) |
1,016 mm (40 in) |
25,400 mm (1000 in) |
11,430 mm (450 in) |
| 機身外殼 |
ABS plastic |
| 機身尺寸 |
204 mm W x 164 mm H x 280 mm D |
| 重量 |
2.4 kg (5.29 lbs) |
2.4 kg (5.29 lbs) |
2.5 kg (5.51 lbs) |
2.5 kg (5.51 lbs) |
| 標籤卷容量 |
127 mm (5 in) OD |
| 碳帶 |
300 m, max. OD 67 mm, 1 in core; 110 m, max. OD 40 mm, 0.5 in core |
| 碳帶寬度 |
40 mm ~ 110 mm (1.6 in ~ 4.3 in) |
| 處理器 |
32-bit RISC CPU |
| 記憶體 |
8 MB Flash / 16 MB SDRAM |
8 MB Flash / 16 MB SDRAM |
128 MB Flash / 64 MB SDRAM |
128 MB Flash / 64 MB SDRAM |
| 連接介面 |
USB 2.0; Internal Bluetooth 4.0 factory option |
USB 2.0; Internal Bluetooth 4.0 factory option |
USB 2.0; Internal Ethernet 10/100 Mbps; RS-232; USB Host; Internal Bluetooth 4.0 factory option |
USB 2.0; Internal Ethernet 10/100 Mbps; RS-232; USB Host; Internal Bluetooth 4.0 factory option |
| 電源 |
AC 100-240V input; DC 24V / 2.5A / 60W output |
| 操作按鍵及 LED |
1 power switch, 1 feed and pause button, 1 LED |
| 感應器 |
Transmissive gap; black mark reflective; ribbon end; head open |
| Real Time Clock |
N/A |
N/A |
Standard |
Standard |
| Buzzer |
N/A |
N/A |
Standard |
Standard |
| 內置字體 |
8 alpha-numeric bitmap fonts; Monotype Image true type font engine with CG Triumvirate Bold Condensed scalable font |
| 1D 條碼 |
Code 128UCC, Code 128, EAN128, Interleaved 2 of 5, Code 39, Code 93, EAN13, EAN8, UPCA, UPCE, Codabar, Postnet, MSI, PLESSEY, China post, ITF14, Code 11, TELEPEN, PLANET, Code49, Deutsche Post, LOGMARS |
| 2D 條碼 |
GS1 DataBar, GS1 DataMatrix, Maxicode, AZTEC, PDF417, QR Code, Micro PDF417 |
| 字體及條碼旋轉 |
0, 90, 180, 270 degree |
| 打印機語言 |
TSPL-EZD, compatible to EPL, ZPL, ZPL II, DPL |
| 標籤紙類型 |
Continuous, die-cut, black mark, fan-fold, notched, outside wound |
| 標籤紙寬度 |
20 ~ 112 mm (0.8 in ~ 4.4 in) |
| 標籤紙厚度 |
0.06 ~ 0.19 mm (2.36 ~ 7.48 mil) |
| 標籤卷芯直徑 |
25.4 ~ 38 mm (1 in ~ 1.5 in) |
| 標籤長度 |
5 ~ 2,794 mm (0.2 in ~ 110 in) |
5 ~ 1,016 mm (0.2 in ~ 40 in) |
5 ~ 25,400 mm (0.2 in ~ 1000 in) |
5 ~ 11,430 mm (0.2 in ~ 450 in) |
| 操作及儲存環境 |
Operation 5 ~ 40 C, 25 ~ 85% non-condensing; storage -40 ~ 60 C, 10 ~ 90% non-condensing |
| 安全規格 |
FCC Class A, CE Class A, C-Tick Class A, UL, cUL, TÜV/safety, CCC, EAC, CoC, BIS, KC, Energy Star |
FCC Class A, CE Class A, C-Tick Class A, UL, cUL, TÜV/safety, CCC, EAC, CoC, BIS, KC, Energy Star |
FCC Class B, CE Class B, C-Tick Class B, UL, cUL, TÜV/safety, CCC, EAC, CoC, BIS, KC, Energy Star |
FCC Class B, CE Class B, C-Tick Class B, UL, cUL, TÜV/safety, CCC, EAC, CoC, BIS, KC, Energy Star |
| 環保規格 |
Comply with RoHS, REACH, WEEE |
| 包裝配件 |
Windows labeling software, quick start guide, USB cable, power cord, external power supply, label spindle, adapters, ribbon spindles, ribbon paper core |
| 有限保養 |
Printer: 2 years; print head: 25 km or 12 months; platen: 50 km or 12 months |
| 出廠選配 |
Internal Bluetooth 4.0 |
| 經銷選配 |
N/A |
N/A |
Peel-off module; guillotine cutter, full cut and partial cut |
Peel-off module; guillotine cutter, full cut and partial cut |
| 用戶選配 |
External roll mount for 214 mm (8.4 in) OD media with 76.2 mm (3 in) core; KP-200 Plus keyboard display unit; KU-007 Plus programmable smart keyboard |
