AN480 RFID ANTENNA

Home » Product » RFID » AN480 RFID ANTENNA

The AN480 single port antenna offers maximum performance and flexibility. The low  axial ratio is nearly 50 percent lower than typical competitive devices, delivering a more  uniform gain — and better performance. The wide frequency range enables this antenna  to be utilized in worldwide deployments, providing cost-efficiencies and a simplified RFID  infrastructure. The AN480 can be installed throughout the enterprise in manufacturing  and warehouse floor environments, or any dock door receiving application. As with all  Zebra antennas, the AN480 uses Zebra’s standard mounting bracket — mounting the  antenna for the first time or upgrading an existing Zebra antenna with the AN480 is fast  and easy.

Categories: , ,

Description

pdf icon

Physical Characteristics

Polarization Left-hand circular or Right-hand circular
Dimensions 259.1 mm X 259.1 mm X 33.5mm / 10.2″ X 10.2″ X 1.32″.
Connector N-Type Female
Connector Location Rear
Weight 2.5lbs. / 1.13kg
Materials Aluminum with white plastic cover
Freguency Ranges 865 – 956 MHz
Gain 6.0 dBiL
Axial Ratio 1.5 dB typical
Maximum Power 2 Watts
Operating Temperature -25° to +70°C/-13° to +158°F
Storage Temperature -40° to +70°C/-40° to +158°F
IP Sealing IP54
