Description
Voyager 9520/VoyagerCG 9540
Single-Line Laser Scanners
Honeywell’s Voyager® 9500 series of hand-held, single-line laser
scanners offer aggressive scanning of all standard 1D bar codes.
The Voyager series of hand-held, single-line bar code scanners have
united form with function in becoming the industry benchmark for value
and performance.
These sleek scanners feature patented automatic infrared activation
and decode all standard 1D bar codes, including GS1 DataBarTM
(formerly known as RSS codes).
VoyagerCG 9540 also includes patented CodeGate® technology which
allows the user to easily target the desired bar code and complete data
transmission with the press of a single button.
For presentation scanning, Honeywell offers a stand with automatic
in-stand detection technology.
Features
• Automatic Trigger: Use scanner as either a hand-held
device or a fixed presentation scanner when mounted in
the stand
• 650-nanometer Laser: High-visibility laser allows user to
place laser line on selected bar code
• CodeGate Technology (VoyagerCG 9540 only): Zero
in on desired code and complete data transmission with
the push of a single button—ideal for menu scanning
applications
• Flash ROM: Future proof POS system with free firmware
updates via MetroSetR2 software and standard PC
• Parsing (Data Editing): Format bar code data to meet
host system’s specific requirements
Voyager 9520/VoyagerCG 9540 Technical Specifications
Mechanical
Dimensions (LxWxH) 198 mm x 78 mm x 56 mm (7.8˝ x 3.1˝ x 2.2˝)
Weight 149 g (5.3 oz)
Electrical
Input Voltage 5 VDC + 0.25 V
Operating Power 825 mW (165 mA @ 5 V)
Standby Power 600 mW (120 mA @ 5 V)
Host System Interfaces USB, RS232, Keyboard Wedge, IBM 46xx (RS485), OCIA, Laser Emulation, Light Pen Wand Emulation
Environmental
Operating Temperature 0°C to 40°C (32°F to 104°F)
Storage Temperature -40°C to 60°C (-40°F to 140°F)
Humidity 5% to 95% relative humidity, non-condensing
Drop Designed to withstand 1.5 m (5’) drops
Environmental Sealing Sealed to resist airborne particulate contaminants
Light Levels 4842 Lux
Scan Performance
Scan Pattern Single scan line
Scan Speed 72 scan lines per second
Scan Angle Horizontal: 50°
Print Contrast 35% minimum reflectance difference
Pitch, Skew 68°, 52°
Decode Capabilities Reads standard 1D and GS1 DataBar symbologies
Warranty 5 year factory warranty
